NKC-5(芳构化)催化剂
NKC-5(C5 Aromatization)Catalyst
1、催化剂适应原料广泛,用于C3、C4气体,直馏汽油,凝析油的芳构化反应。
2、用于将碳五馏分转变为苯(B)、甲苯(T)、二甲苯(X),并副产乙烯、丙烯、乙烷、丙烷等有价值产品的催化剂。
适用原料:乙烯工程的副产品C3~C7
特点:反应转化率高,芳烃收率高,抗结焦能力强,尤其适用于高烯烃含量的C5原料,允许原料中烯烃含量达80%。经使用证明该催化剂在轻烃(C3~C7)芳构化及生产高辛烷值汽油的反应中也具有优良的催化性能。
The NKC-5 Catalyst For C5 Aromatization
The NKC-5 Catalyst for C5 to aromatics is based on a synthetic zeolite. The catelyst can convert alkane or alkene of C5 to aromatics mainly containing benzene(B), toluene(T) and xylenes(X), accompanied by the production of hydrogen and C1-C4 organic gases.By coinversion of C5 hydrocarbon,the valuble aromatics, ethene,propene and liquefied petroleum gas can be obtained. So the application of this catalyst is extremely profitable.
The NKC-5 Catalyst has become commercial,and has been used for about 3 year by the Danhua Group Co.,Jiangsu Proviince with an annual treatment of 30.000 tons C5. The concersion of C5 is more than 95%,and the yield of aromatics ranges from 60% to 70%.C3,C4 account for 50% of the organic gases produced,and ethene,propene for about 20%.
The NKC-5 Catalyst,with its remarkable stability and resistance to coking,could tolerate the feedstock containing 80% alkene of C5 .
Result of the aromatization of distillate C5 .
使用条件
空速 (Space Velocity) |
0.6~1.0 h-1(W/W) |
反应温度 (Reaction Temperature) |
450~570℃ |
反应压力 (Reaction Pressure) |
常压(NPT) |
碳五转化率 (Conversation of C5) |
>95% |
产物组成 (Product composition) |
70% Liquid; 30% Gas |
催化剂单程寿命 (One-way Catalyst Life) |
烷烃(Alkanes)>200h, 烯烃(Olefin)>24h |
再生周期 (Regeneration cycle) |
<20h |
总寿命 (Total life) |
>8 months |
产物结果如下表(某一装置数据)
A typical result of the reaction in a pilot reactor is given as follows
液体产物分析 (Liquid Composition) |
碳五 (C5) |
苯 (Benzene) |
甲苯 (Toluene) |
二甲苯(Xylene) |
其它 (Others) |
/ |
/ |
1.80 |
22.40 |
45.79 |
25.23 |
4.80 |
/ |
气体产物分析 (Gas Composition) |
甲烷 (Methane) |
乙烷 (Ethane) |
乙烯 (Ethylene) |
丙烷 (Propane) |
丙烯 (Propylene) |
碳四 (C4) |
/ |
13.12 |
17.96 |
7.70 |
41.45 |
6.85 |
13.56 |
运输:非危险品,但运输过程中要避免潮湿,保持干燥、密封。
Transportation:Non-dangerous goods, in transportation process avoid wet. Keep dry and airproof.
储存方法:在干燥、透风处贮存,不得露天存放。
Storage Method:Deposit in dry place and vent, not in the open air.
NKC®的产品符合优质的标准,受到全球研究人员和工程师的信赖。
NKC® Products are trusted by researchers and engineers worldwide for meeting the standards of excellence.
NKC® can provide packages:100g, 250g, 500g, 1kg, 10kg, 1000kg or based on your need.
